Description

Standard version:

CybTouch 8 touchscreen NC control in the swivel arm NC-controlled backgauge (5-1000mm) driven via recirculating ball screws and guided linearly Safety light curtain for the rear area Motorized cutting gap adjustment via the control unit 1500 mm side fence with scale and T-slot Front support arms 1000mm with scale and T-slot Stainless steel table supports with integrated transfer balls Hold-down device with plastic caps to protect the material Variable cutting length adjustment via the control unit Folding finger guard 1000mm with viewing window inserts Sheet chute in the rear area Cutting line lighting with silhouette Knives suitable for cutting stainless steel Upper blade with two cutting edges and lower blade with four cutting edges Electrical components from Schneider and Mitsubishi Equipment options:

Adjustable angle fence Laser cutting line display Front light barrier instead of finger guard Finger guard can be opened over the entire length Additional front support arms Additional side stop on the right Extensions of the standard support arms, the side or back gauge Transfer ball in the side stop and the front support arms Servo motor for the back gauge Manual or automatic central lubrication Pneumatic sheet support systems Small parts diverter with pneumatic opening Oil cooler or oil warmer

• Braced machine bed made of gray cast iron
• Elaborate spindle bearing
